Acoustic Ceiling Cloud
Enhance your space with our acoustic ceiling clouds, thoughtfully designed to reduce noise and improve sound quality. These suspended panels effectively absorb sound, minimizing echoes and reverberation to create a more comfortable and balanced environment. Ideal for offices, auditoriums, and open-plan areas, they blend seamlessly with any décor while delivering superior acoustic performance. Experience the perfect balance of functionality and aesthetics with our acoustic ceiling clouds.
KEY FEATURES
- Outstanding sound absorption with amazing look
- Formaldehyde free
- Fire retardant (self-extinguishing)
- No toxic gas when burning
- 100% Polyester Fibr
Installation Method
Layout & Marking
- Mark the exact position of the ceiling cloud as per approved drawing.
- Identify suspension points (usually 4 points per panel or as per size).
Fix Anchor Fasteners
- Drill holes in RCC slab at marked suspension points.
- Insert and tighten anchor fasteners securely.
Install Hanging Wire
- Fix GI / SS hanging wire (2.5–3 mm dia) to anchor fasteners.
- Cut wire to required drop height.
- Ensure all wires are equal length for proper leveling.
Attach Suspension Hooks / Eye Bolts
- Fix eye bolts or suspension clips to the acoustic cloud panel frame.
- Connect hanging wires to the panel hooks securely.
Leveling & Alignment
- Adjust wire lengths to achieve proper level.
- Ensure panel is straight and stable from all sides.
Final Check
- Tighten all connections.
- Verify load stability and alignment.
- Clean panel surface after installation.
